LVS+Keepalived 方法总结


LVS+Keepalived配置总结

keepalived 控制虚IP(VIP)在master和backup的IP接口上的漂移

通过service keepalived start|stop来控制服务

如下:

[root@node220 ~]# ip addr

1: lo: <LOOPBACK,UP,LOWER_UP> mtu 16436 qdiscnoqueue

    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00

    inet127.0.0.1/8 scope host lo

2: eth0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500qdisc pfifo_fast qlen 1000

    link/ether00:0c:29:0f:e6:5a brd ff:ff:ff:ff:ff:ff

    inet192.168.2.220/16 brd 192.168.255.255 scope global eth0

    inet192.168.2.118/32 scope global eth0

3: eth1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500qdisc pfifo_fast qlen 1000

    link/ether 00:0c:29:0f:e6:64 brdff:ff:ff:ff:ff:ff

    inet172.16.1.1/24 brd 172.16.1.255 scope global eth1

[root@node220 ~]# service keepalived stop

Stopping keepalived:                                       [  OK  ]

[root@node220 ~]# ip addr

1: lo: <LOOPBACK,UP,LOWER_UP> mtu 16436 qdiscnoqueue

   link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00

    inet127.0.0.1/8 scope host lo

2: eth0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu1500 qdisc pfifo_fast qlen 1000

    link/ether00:0c:29:0f:e6:5a brd ff:ff:ff:ff:ff:ff

    inet192.168.2.220/16 brd 192.168.255.255 scope global eth0

3: eth1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu1500 qdisc pfifo_fast qlen 1000

    link/ether00:0c:29:0f:e6:64 brd ff:ff:ff:ff:ff:ff

    inet172.16.1.1/24 brd 172.16.1.255 scope global eth1



LVS控制虚拟IP地址与后端真实服务器的对应关系:

LVS由ipvsadm来控制配置文件的保存和服务器启动

[root@node220 ~]# service ipvsadm start

Clearing the current IPVS table:                           [  OK  ]

Applying IPVS configuration:                               [  OK  ]

[root@node220 ~]# service ipvsadm status

IP Virtual Server version 1.2.1 (size=4096)

Prot LocalAddress:Port Scheduler Flags

  ->RemoteAddress:Port           ForwardWeight ActiveConn InActConn

TCP 192.168.2.118:80 rr persistent 300

  ->192.168.2.222:80             Route   10    0          0

[root@node220 ~]# service ipvsadm stop

Clearing the current IPVS table:                           [  OK  ]

[root@node220 ~]# service ipvsadm status

IP Virtual Server version 1.2.1 (size=4096)

Prot LocalAddress:Port Scheduler Flags

  ->RemoteAddress:Port           ForwardWeight ActiveConn InActConn



可以通过service ipvsadm save 将配置信息保存在/etc/sysconfig/ipvsadm

[root@node220 ~]# service ipvsadm save

Saving IPVS table to /etc/sysconfig/ipvsadm:               [  OK  ]
