安装完成后快速启动服务：
启用服务：
cd /root/archery_1.13.0/src/docker-compose/
docker-compose -f docker-compose.yml up -d

在容器启动后，对容器内的静态文件进行初始化文件复制
docker exec archery bash -c "cp -r  /opt/static/* /opt/archery/static/"


浏览器登录：
http://172.16.1.111:9123
admin/admin888

++++++++++++++++++++++++++++++++++++
1.安装部署操作系统环境：
[root@centos7 docker-compose]# cat /etc/redhat-release
CentOS Linux release 7.9.2009 (Core)
[root@centos7 docker-compose]# uname -a
Linux centos7.9 3.10.0-1160.el7.x86_64 #1 SMP Mon Oct 19 16:18:59 UTC 2020 x86_64 x86_64 x86_64 GNU/Linux
[root@centos7 docker-compose]#

2.修改centos7软件包阿里云源
cd /etc/yum.repos.d/
mv /etc/yum.repos.d/CentOS-Base.repo /etc/yum.repos.d/CentOS-Base.repo.backup
curl -O http://mirrors.aliyun.com/repo/Centos-7.repo
mv Centos-7.repo CentOS-Base.repo
yum install lrzsz nmap wget nmap gcc gcc-c++


3.安装docker软件
3.1 安装docker
yum install -y yum-utils device-mapper-persistent-data lvm2


#紧接着配置一个稳定的仓库、仓库配置会保存到/etc/yum.repos.d/docker-ce.repo文件中
yum-config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo


#更新Yum安装的相关Docker软件包&安装Docker CE
yum install docker-ce
##yum update -y


3.2 设置docker daemon文件
#创建/etc/docker目录
mkdir /etc/docker


#更新daemon.json文件
cat > /etc/docker/daemon.json <<EOF
{"exec-opts":["native.cgroupdriver=systemd"],"log-driver":"json-file","log-opts":{"max-size":"100m"}}
EOF


#注意：一定注意编码问题，出现错误---查看命令：journalctl -amu docker 即可发现错误
#创建，存储docker配置文件
mkdir -p /etc/systemd/system/docker.service.d


3.3 重启docker服务
systemctl daemon-reload && systemctl restart docker && systemctl enable docker




4.安装docker compose (需要梯子)
sudo curl -L "https://github.com/docker/compose/releases/download/1.24.1/docker-compose-$(uname -s)-$(uname -m)" -o /usr/local/bin/docker-compose
sudo chmod +x /usr/local/bin/docker-compose


5.下载官方安装包：(v.1.13.0)
wget https://github.com/hhyo/Archery/archive/refs/tags/v1.13.0.tar.gz


6.将软件包解压缩到指定的文件夹
tar xf v1.13.0.tar.gz -C /root/
[root@centos7 docker-compose]# pwd
/root/archery-1.13.0/src/docker-compose
[root@centos7 docker-compose]# ls
archery  docker-compose.yml  inception  mysql
[root@centos7 docker-compose]# cp ./.env ./archery/


7.编译settings.py文件，
默认情况下/root/archery-1.13.0/src/docker-compose/archery这个目录下的settings.py文件为空，需要将以下配置复制到settings.py中
# -*- coding: UTF-8 -*-




# Build paths inside the project like this: os.path.join(BASE_DIR, ...)
import os
from typing import List
from datetime import timedelta
import environ
import requests
import logging


logging.basicConfig(
    level=logging.INFO, format="%(asctime)s - %(name)s - %(levelname)s - %(message)s"
)
logger = logging.getLogger(__name__)


BASE_DIR = os.path.dirname(os.path.dirname(os.path.abspath(__file__)))


environ.Env.read_env(os.path.join(BASE_DIR, ".env"))
env = environ.Env(
    DEBUG=(bool, False),
    ALLOWED_HOSTS=(list, ["*"]),
    SECRET_KEY=(
        str,
        "adfqwefqefqewfkjasidfjpqefuqpeujqwfepoiqwejf",
    ),  # 参考 https://docs.djangoproject.com/zh-hans/4.0/ref/settings/#secret-key
    DATABASE_URL=(str, "mysql://root:@127.0.0.1:3306/archery"),
    CACHE_URL=(str, "redis://127.0.0.1:6379/0"),
    # 系统外部认证目前支持LDAP、OIDC、DINGDING三种，认证方式只能启用其中一种，如果启用多个，实际生效的只有一个，优先级LDAP > DINGDING > OIDC
    ENABLE_LDAP=(bool, False),
    ENABLE_OIDC=(bool, False),
    ENABLE_DINGDING=(
        bool,
        False,
    ),  # 钉钉认证方式参考文档：https://open.dingtalk.com/document/orgapp/tutorial-obtaining-user-personal-information
    AUTH_LDAP_ALWAYS_UPDATE_USER=(bool, True),
    AUTH_LDAP_USER_ATTR_MAP=(
        dict,
        {"username": "cn", "display": "displayname", "email": "mail"},
    ),
    Q_CLUISTER_SYNC=(bool, False),  # qcluster 同步模式, debug 时可以调整为 True
    # CSRF_TRUSTED_ORIGINS=subdomain.example.com,subdomain.example2.com subdomain.example.com
    CSRF_TRUSTED_ORIGINS=(list, []),
    ENABLED_ENGINES=(
        list,
        [
            "mysql",
            "clickhouse",
            "goinception",
            "mssql",
            "redis",
            "pgsql",
            "oracle",
            "mongo",
            "phoenix",
            "odps",
            "cassandra",
            "doris",
            "elasticsearch",
            "opensearch",
        ],
    ),
    ENABLED_NOTIFIERS=(
        list,
        [
            "sql.notify:DingdingWebhookNotifier",
            "sql.notify:DingdingPersonNotifier",
            "sql.notify:FeishuWebhookNotifier",
            "sql.notify:FeishuPersonNotifier",
            "sql.notify:QywxWebhookNotifier",
            "sql.notify:QywxToUserNotifier",
            "sql.notify:MailNotifier",
            "sql.notify:GenericWebhookNotifier",
        ],
    ),
    CURRENT_AUDITOR=(str, "sql.utils.workflow_audit:AuditV2"),
    PASSWORD_MIXIN_PATH=(str, "sql.plugins.password:DummyMixin"),
)


# SECURITY WARNING: keep the secret key used in production secret!
SECRET_KEY = env("SECRET_KEY")


# SECURITY WARNING: don't run with debug turned on in production!
DEBUG = env("DEBUG")


ALLOWED_HOSTS = env("ALLOWED_HOSTS")


# https://docs.djangoproject.com/en/4.0/ref/settings/#csrf-trusted-origins
CSRF_TRUSTED_ORIGINS = env("CSRF_TRUSTED_ORIGINS")


# 解决nginx部署跳转404
USE_X_FORWARDED_HOST = True


# 请求限制
DATA_UPLOAD_MAX_MEMORY_SIZE = 15728640


AVAILABLE_ENGINES = {
    "mysql": {"path": "sql.engines.mysql:MysqlEngine"},
    "cassandra": {"path": "sql.engines.cassandra:CassandraEngine"},
    "clickhouse": {"path": "sql.engines.clickhouse:ClickHouseEngine"},
    "goinception": {"path": "sql.engines.goinception:GoInceptionEngine"},
    "mssql": {"path": "sql.engines.mssql:MssqlEngine"},
    "redis": {"path": "sql.engines.redis:RedisEngine"},
    "pgsql": {"path": "sql.engines.pgsql:PgSQLEngine"},
    "oracle": {"path": "sql.engines.oracle:OracleEngine"},
    "mongo": {"path": "sql.engines.mongo:MongoEngine"},
    "phoenix": {"path": "sql.engines.phoenix:PhoenixEngine"},
    "odps": {"path": "sql.engines.odps:ODPSEngine"},
    "doris": {"path": "sql.engines.doris:DorisEngine"},
    "elasticsearch": {"path": "sql.engines.elasticsearch:ElasticsearchEngine"},
    "opensearch": {"path": "sql.engines.elasticsearch:OpenSearchEngine"},
}


ENABLED_NOTIFIERS = env("ENABLED_NOTIFIERS")


ENABLED_ENGINES = env("ENABLED_ENGINES")


CURRENT_AUDITOR = env("CURRENT_AUDITOR")


PASSWORD_MIXIN_PATH = env("PASSWORD_MIXIN_PATH")


# Application definition
INSTALLED_APPS = (
    "django.contrib.admin",
    "django.contrib.auth",
    "django.contrib.contenttypes",
    "django.contrib.sessions",
    "django.contrib.messages",
    "django.contrib.staticfiles",
    "django_q",
    "sql",
    "sql_api",
    "common",
    "rest_framework",
    "django_filters",
    "drf_spectacular",
)


MIDDLEWARE = (
    "django.contrib.sessions.middleware.SessionMiddleware",
    "django.middleware.common.CommonMiddleware",
    "django.middleware.csrf.CsrfViewMiddleware",
    "django.contrib.auth.middleware.AuthenticationMiddleware",
    "django.contrib.messages.middleware.MessageMiddleware",
    "django.middleware.clickjacking.XFrameOptionsMiddleware",
    "django.middleware.security.SecurityMiddleware",
    "django.middleware.gzip.GZipMiddleware",
    "common.middleware.check_login_middleware.CheckLoginMiddleware",
    "common.middleware.exception_logging_middleware.ExceptionLoggingMiddleware",
)


ROOT_URLCONF = "archery.urls"


TEMPLATES = [
    {
        "BACKEND": "django.template.backends.django.DjangoTemplates",
        "DIRS": [os.path.join(BASE_DIR, "common/templates")],
        "APP_DIRS": True,
        "OPTIONS": {
            "context_processors": [
                "django.template.context_processors.debug",
                "django.template.context_processors.request",
                "django.contrib.auth.context_processors.auth",
                "django.contrib.messages.context_processors.messages",
                "common.utils.global_info.global_info",
            ],
        },
    },
]


WSGI_APPLICATION = "archery.wsgi.application"


# Internationalization
LANGUAGE_CODE = "zh-hans"


TIME_ZONE = "Asia/Shanghai"


USE_I18N = True


USE_TZ = False


# 时间格式化
USE_L10N = False
DATETIME_FORMAT = "Y-m-d H:i:s"
DATE_FORMAT = "Y-m-d"


# Static files (CSS, JavaScript, Images)
STATIC_URL = "/static/"
STATIC_ROOT = os.path.join(BASE_DIR, "static")
STATICFILES_DIRS = [
    os.path.join(BASE_DIR, "common/static"),
]
STATICFILES_STORAGE = "common.storage.ForgivingManifestStaticFilesStorage"


# 扩展django admin里users字段用到，指定了sql/models.py里的class users
AUTH_USER_MODEL = "sql.Users"


# 密码校验
AUTH_PASSWORD_VALIDATORS = [
    {
        "NAME": "django.contrib.auth.password_validation.UserAttributeSimilarityValidator",
    },
    {
        "NAME": "django.contrib.auth.password_validation.MinimumLengthValidator",
        "OPTIONS": {
            "min_length": 9,
        },
    },
    {
        "NAME": "django.contrib.auth.password_validation.CommonPasswordValidator",
    },
    {
        "NAME": "django.contrib.auth.password_validation.NumericPasswordValidator",
    },
]


############### 以下部分需要用户根据自己环境自行修改 ###################


# SESSION 设置
SESSION_COOKIE_AGE = 60 * 300  # 300分钟
SESSION_SAVE_EVERY_REQUEST = True
SESSION_EXPIRE_AT_BROWSER_CLOSE = True  # 关闭浏览器，则COOKIE失效


# 该项目本身的mysql数据库地址
DATABASES = {
    "default": {
        **env.db(),
        **{
            "DEFAULT_CHARSET": "utf8mb4",
            "CONN_MAX_AGE": 50,
            "OPTIONS": {
                "init_command": "SET sql_mode='STRICT_TRANS_TABLES'",
                "charset": "utf8mb4",
            },
            "TEST": {
                "NAME": "test_archery",
                "CHARSET": "utf8mb4",
            },
        },
    }
}


# Django-Q
Q_CLUSTER = {
    "name": "archery",
    "workers": env("Q_CLUISTER_WORKERS", default=4),
    "recycle": 500,
    "timeout": env("Q_CLUISTER_TIMEOUT", default=60),
    "compress": True,
    "cpu_affinity": 1,
    "save_limit": 0,
    "queue_limit": 50,
    "label": "Django Q",
    "django_redis": "default",
    "sync": env("Q_CLUISTER_SYNC"),  # 本地调试可以修改为True，使用同步模式
}


# 缓存配置
CACHES = {
    "default": env.cache(),
}


# https://docs.djangoproject.com/en/3.2/ref/settings/#std-setting-DEFAULT_AUTO_FIELD
DEFAULT_AUTO_FIELD = "django.db.models.AutoField"


# API Framework
REST_FRAMEWORK = {
    "DEFAULT_SCHEMA_CLASS": "drf_spectacular.openapi.AutoSchema",
    "DEFAULT_RENDERER_CLASSES": ("rest_framework.renderers.JSONRenderer",),
    # 鉴权
    "DEFAULT_AUTHENTICATION_CLASSES": (
        "rest_framework_simplejwt.authentication.JWTAuthentication",
        "rest_framework.authentication.SessionAuthentication",
    ),
    # 权限
    "DEFAULT_PERMISSION_CLASSES": ("sql_api.permissions.IsInUserWhitelist",),
    # 限速（anon：未认证用户  user：认证用户）
    "DEFAULT_THROTTLE_CLASSES": (
        "rest_framework.throttling.AnonRateThrottle",
        "rest_framework.throttling.UserRateThrottle",
    ),
    "DEFAULT_THROTTLE_RATES": {"anon": "120/min", "user": "600/min"},
    # 过滤
    "DEFAULT_FILTER_BACKENDS": ("django_filters.rest_framework.DjangoFilterBackend",),
    # 分页
    "DEFAULT_PAGINATION_CLASS": "rest_framework.pagination.PageNumberPagination",
    "PAGE_SIZE": 5,
}


# Swagger UI
SPECTACULAR_SETTINGS = {
    "TITLE": "Archery API",
    "DESCRIPTION": "OpenAPI 3.0",
    "VERSION": "1.0.0",
}


# API Authentication
SIMPLE_JWT = {
    "ACCESS_TOKEN_LIFETIME": timedelta(hours=4),
    "REFRESH_TOKEN_LIFETIME": timedelta(days=3),
    "ALGORITHM": "HS256",
    "SIGNING_KEY": SECRET_KEY,
    "AUTH_HEADER_TYPES": ("Bearer",),
}


# OIDC
ENABLE_OIDC = env("ENABLE_OIDC", False)
if ENABLE_OIDC:
    INSTALLED_APPS += ("mozilla_django_oidc",)
    AUTHENTICATION_BACKENDS = (
        "common.authenticate.oidc_auth.OIDCAuthenticationBackend",
        "django.contrib.auth.backends.ModelBackend",
    )


    OIDC_RP_WELLKNOWN_URL = env(
        "OIDC_RP_WELLKNOWN_URL"
    )  # 例如 https://keycloak.example.com/realms/<your realm>/.well-known/openid-configuration
    OIDC_RP_CLIENT_ID = env("OIDC_RP_CLIENT_ID")
    OIDC_RP_CLIENT_SECRET = env("OIDC_RP_CLIENT_SECRET")


    response = requests.get(OIDC_RP_WELLKNOWN_URL)
    response.raise_for_status()
    config = response.json()
    OIDC_OP_AUTHORIZATION_ENDPOINT = config["authorization_endpoint"]
    OIDC_OP_TOKEN_ENDPOINT = config["token_endpoint"]
    OIDC_OP_USER_ENDPOINT = config["userinfo_endpoint"]
    OIDC_OP_JWKS_ENDPOINT = config["jwks_uri"]
    OIDC_OP_LOGOUT_ENDPOINT = config["end_session_endpoint"]


    OIDC_RP_SCOPES = env("OIDC_RP_SCOPES", default="openid profile email")
    OIDC_RP_SIGN_ALGO = env("OIDC_RP_SIGN_ALGO", default="RS256")


    LOGIN_REDIRECT_URL = "/"


# Dingding
ENABLE_DINGDING = env("ENABLE_DINGDING", False)
if ENABLE_DINGDING:
    INSTALLED_APPS += ("django_auth_dingding",)
    AUTHENTICATION_BACKENDS = (
        "common.authenticate.dingding_auth.DingdingAuthenticationBackend",
        "django.contrib.auth.backends.ModelBackend",
    )
    AUTH_DINGDING_AUTHENTICATION_CALLBACK_URL = env(
        "AUTH_DINGDING_AUTHENTICATION_CALLBACK_URL"
    )
    AUTH_DINGDING_APP_KEY = env("AUTH_DINGDING_APP_KEY")
    AUTH_DINGDING_APP_SECRET = env("AUTH_DINGDING_APP_SECRET")


# LDAP
ENABLE_LDAP = env("ENABLE_LDAP", False)
if ENABLE_LDAP:
    import ldap
    from django_auth_ldap.config import LDAPSearch


    AUTHENTICATION_BACKENDS = (
        "django_auth_ldap.backend.LDAPBackend",  # 配置为先使用LDAP认证，如通过认证则不再使用后面的认证方式
        "django.contrib.auth.backends.ModelBackend",  # django系统中手动创建的用户也可使用，优先级靠后。注意这2行的顺序
    )


    AUTH_LDAP_SERVER_URI = env("AUTH_LDAP_SERVER_URI", default="ldap://xxx")
    AUTH_LDAP_USER_DN_TEMPLATE = env("AUTH_LDAP_USER_DN_TEMPLATE", default=None)
    if not AUTH_LDAP_USER_DN_TEMPLATE:
        del AUTH_LDAP_USER_DN_TEMPLATE
        AUTH_LDAP_BIND_DN = env(
            "AUTH_LDAP_BIND_DN", default="cn=xxx,ou=xxx,dc=xxx,dc=xxx"
        )
        AUTH_LDAP_BIND_PASSWORD = env("AUTH_LDAP_BIND_PASSWORD", default="***********")
        AUTH_LDAP_USER_SEARCH_BASE = env(
            "AUTH_LDAP_USER_SEARCH_BASE", default="ou=xxx,dc=xxx,dc=xxx"
        )
        AUTH_LDAP_USER_SEARCH_FILTER = env(
            "AUTH_LDAP_USER_SEARCH_FILTER", default="(cn=%(user)s)"
        )
        AUTH_LDAP_USER_SEARCH = LDAPSearch(
            AUTH_LDAP_USER_SEARCH_BASE, ldap.SCOPE_SUBTREE, AUTH_LDAP_USER_SEARCH_FILTER
        )
    AUTH_LDAP_ALWAYS_UPDATE_USER = env(
        "AUTH_LDAP_ALWAYS_UPDATE_USER", default=True
    )  # 每次登录从ldap同步用户信息
    AUTH_LDAP_USER_ATTR_MAP = env("AUTH_LDAP_USER_ATTR_MAP")


# CAS认证
ENABLE_CAS = env("ENABLE_CAS", default=False)
if ENABLE_CAS:
    INSTALLED_APPS += ("django_cas_ng",)
    MIDDLEWARE += ("django_cas_ng.middleware.CASMiddleware",)
    AUTHENTICATION_BACKENDS = (
        "django.contrib.auth.backends.ModelBackend",
        "django_cas_ng.backends.CASBackend",
    )


    # CAS 的地址
    CAS_SERVER_URL = env("CAS_SERVER_URL")
    # CAS 版本
    CAS_VERSION = env("CAS_VERSION")
    # 存入所有 CAS 服务端返回的 User 数据。
    CAS_APPLY_ATTRIBUTES_TO_USER = True
    # 关闭浏览器退出登录
    SESSION_EXPIRE_AT_BROWSER_CLOSE = True
    #  忽略  SSL  证书校验
    CAS_VERIFY_SSL_CERTIFICATE = env("CAS_VERIFY_SSL_CERTIFICATE", default=False)
    #  忽略来源验证
    CAS_IGNORE_REFERER = True
    # https请求问题
    CAS_FORCE_SSL_SERVICE_URL = env("CAS_FORCE_SSL_SERVICE_URL", default=False)
    CAS_RETRY_TIMEOUT = 1
    CAS_RETRY_LOGIN = True
    CAS_EXTRA_LOGIN_PARAMS = {"renew": True}
    CAS_LOGOUT_COMPLETELY = True


SUPPORTED_AUTHENTICATION = [
    ("LDAP", ENABLE_LDAP),
    ("DINGDING", ENABLE_DINGDING),
    ("OIDC", ENABLE_OIDC),
    ("CAS", ENABLE_CAS),
]
# 计算当前启用的外部认证方式数量
ENABLE_AUTHENTICATION_COUNT = len(
    [enabled for (name, enabled) in SUPPORTED_AUTHENTICATION if enabled]
)
if ENABLE_AUTHENTICATION_COUNT > 0:
    if ENABLE_AUTHENTICATION_COUNT > 1:
        logger.warning(
            "系统外部认证目前支持LDAP、DINGDING、OIDC、CAS四种，认证方式只能启用其中一种，如果启用多个，实际生效的只有一个，优先级LDAP > DINGDING > OIDC > CAS"
        )
    authentication = ""  # 默认为空
    for name, enabled in SUPPORTED_AUTHENTICATION:
        if enabled:
            authentication = name
            break
    logger.info("当前生效的外部认证方式：" + authentication)
    logger.info("认证后端：" + AUTHENTICATION_BACKENDS.__str__())


# LOG配置
LOGGING = {
    "version": 1,
    "disable_existing_loggers": False,
    "formatters": {
        "verbose": {
            "format": "[%(asctime)s][%(threadName)s:%(thread)d][task_id:%(name)s][%(filename)s:%(lineno)d][%(levelname)s]- %(message)s"
        },
    },
    "handlers": {
        "default": {
            "level": "DEBUG",
            "class": "logging.handlers.RotatingFileHandler",
            "filename": "logs/archery.log",
            "maxBytes": 1024 * 1024 * 100,  # 5 MB
            "backupCount": 5,
            "formatter": "verbose",
        },
        "django-q": {
            "level": "DEBUG",
            "class": "logging.handlers.RotatingFileHandler",
            "filename": "logs/qcluster.log",
            "maxBytes": 1024 * 1024 * 100,  # 5 MB
            "backupCount": 5,
            "formatter": "verbose",
        },
        "console": {
            "level": "DEBUG",
            "class": "logging.StreamHandler",
            "formatter": "verbose",
        },
    },
    "loggers": {
        "default": {  # default日志
            "handlers": ["console", "default"],
            "level": "WARNING",
        },
        "django-q": {  # django_q模块相关日志
            "handlers": ["console", "django-q"],
            "level": "WARNING",
            "propagate": False,
        },
        "django_auth_ldap": {  # django_auth_ldap模块相关日志
            "handlers": ["console", "default"],
            "level": "WARNING",
            "propagate": False,
        },
        "mozilla_django_oidc": {
            "handlers": ["console", "default"],
            "level": "WARNING",
            "propagate": False,
        },
        # 'django.db': {  # 打印SQL语句，方便开发
        #     'handlers': ['console', 'default'],
        #     'level': 'DEBUG',
        #     'propagate': False
        # },
        # 'django.request': {  # 打印请求错误堆栈信息，方便开发
        #     'handlers': ['console', 'default'],
        #     'level': 'DEBUG',
        #     'propagate': False
        # },
    },
}


# 在网站标题及登录页面追加此内容, 可用于多archery实例的区分。Archery后台也有相同配置，如都做了配置，以后台配置为准
CUSTOM_TITLE_SUFFIX = env("CUSTOM_TITLE_SUFFIX", default="")


MEDIA_ROOT = os.path.join(BASE_DIR, "media")
if not os.path.exists(MEDIA_ROOT):
    os.mkdir(MEDIA_ROOT)


PKEY_ROOT = os.path.join(MEDIA_ROOT, "keys")
if not os.path.exists(PKEY_ROOT):
    os.mkdir(PKEY_ROOT)


try:
    from local_settings import *
except ImportError:
    print("import local settings failed, ignored")







8.解压后进入docker-compose文件夹,重新编译docker-compose.yml文件
cat docker-compose.yml
version: '2.4'


services:
  redis:
    image: redis:5
    container_name: redis
    restart: always
    command: redis-server --requirepass 123456
    expose:
      - "6379"
    healthcheck:
      test: [ "CMD", "redis-cli", "ping" ]
      interval: 5s
      timeout: 5s
      retries: 5


  mysql:
    image: mysql:5.7
    container_name: mysql
    restart: always
    ports:
      - "3306:3306"
    volumes:
      - "./mysql/my.cnf:/etc/mysql/my.cnf"
      - "./mysql/datadir:/var/lib/mysql"
    environment:
      MYSQL_DATABASE: archery
      MYSQL_ROOT_PASSWORD: 123456
    healthcheck:
      test: ["CMD", "mysqladmin", "ping"]
      interval: 5s
      timeout: 5s
      retries: 5


  goinception:
    image: hanchuanchuan/goinception
    container_name: goinception
    restart: always
    ports:
      - "4000:4000"
    environment:
      - TZ=Asia/Shanghai
    volumes:
      - "./inception/config.toml:/etc/config.toml"


  archery:
    # 下方的镜像地址仅为示例, 请前往以下地址确认你需要的版本:
    # dockerhub https://hub.docker.com/r/hhyo/archery
    # github packages https://github.com/hhyo/Archery/pkgs/container/archery
    # 如有需要, 也可以自行build docker 镜像, 替换为自己的镜像
    image: hhyo/archery:v1.13.0
    container_name: archery
    restart: always
    depends_on:
      redis:
        condition: service_healthy
      mysql:
        condition: service_healthy
    ports:
      - "9123:9123"
    volumes:
      - "./archery/settings.py:/opt/archery/local_settings.py"
      - "./archery/soar.yaml:/etc/soar.yaml"
      - "./archery/docs.md:/opt/archery/docs/docs.md"
      - "./archery/downloads:/opt/archery/downloads"
      - "./archery/sql/migrations:/opt/archery/sql/migrations"
      - "./archery/logs:/opt/archery/logs"
      - "./archery/keys:/opt/archery/keys"
      - "./archery/.env:/opt/archery/.env"
      - "./archery/.env:/opt/.env"
    entrypoint: ["bash", "-c"]
    command: ["mkdir -p /opt/common/static && mkdir -p /opt/archery/static/ && chmod 755 /opt/archery/src/docker/startup.sh && /opt/archery/src/docker/startup.sh"]
    env_file:
      - .env


8.通过docker-compose.yml文件,自动拉到镜像并启动容器
docker-compose -f docker-compose.yml up -d


9.启动容器后的情况：
[root@centos7 docker-compose]# docker ps -a
CONTAINER ID   IMAGE                       COMMAND                   CREATED             STATUS                 PORTS                                                  NAMES
e569caf3711d   hhyo/archery:v1.13.0        "bash -c 'mkdir -p /…"   About an hour ago   Up About an hour       0.0.0.0:9123->9123/tcp, :::9123->9123/tcp              archery
f7cac781b9d6   hanchuanchuan/goinception   "/usr/local/bin/dumb…"   5 hours ago         Up 5 hours             0.0.0.0:4000->4000/tcp, :::4000->4000/tcp              goinception
9e566422a8b7   mysql:5.7                   "docker-entrypoint.s…"   5 hours ago         Up 5 hours (healthy)   0.0.0.0:3306->3306/tcp, :::3306->3306/tcp, 33060/tcp   mysql
d13b5e918e0c   redis:5                     "docker-entrypoint.s…"   5 hours ago         Up 5 hours (healthy)   6379/tcp


[root@centos7 docker-compose]# docker images
REPOSITORY                  TAG       IMAGE ID       CREATED         SIZE
hhyo/archery                v1.13.0   6713660d744e   4 months ago    2.16GB
hanchuanchuan/goinception   latest    d0fd80a2747e   16 months ago   125MB
mysql                       5.7       5107333e08a8   2 years ago     501MB
redis                       5         99ee9af2b6b1   3 years ago     110MB




10.容器启动后，进入archery中进行数据初始化(注意：一次性操作)
# 表结构初始化
docker exec -ti archery /bin/bash
cd /opt/archery
source /opt/venv4archery/bin/activate
python3 manage.py makemigrations sql
python3 manage.py migrate


# 数据初始化
python3 manage.py dbshell<sql/fixtures/auth_group.sql
python3 manage.py dbshell<src/init_sql/mysql_slow_query_review.sql


# 创建超级管理员用户
python3 manage.py createsuperuser


# 退出容器
exit


# 日志查看和问题排查
docker logs archery -f --tail=50


11.在容器启动后，对容器内的静态文件进行初始化文件复制
docker exec archery bash -c "cp -r  /opt/static/* /opt/archery/static/"


12.打开浏览器输入http://ip:9123进行登录页面


13.在archery中使用goInception
位置:系统管理->配置项管理->系统设置：


GO_INCEPTION_HOST：连接地址，docker-compose启动的请配置为容器名或者docker的ip地址


GO_INCEPTION_PORT：goInception的连接端口，默认4000


BACKUP_HOST：备份库链接HOST，用于页面展示回滚语句


BACKUP_PORT：备份库链接端口


BACKUP_USER：备份库链接用户


BACKUP_PASSWORD：备份库链接密码
